Interfaces

• 6 ports 10/100/1000Base-T

• 2 USB 2.0 ports1

• Console port with mini-USB connector

Indicators

• Power

• Link/Activity/Speed (per port)

Buttons

• Reset Button

• Button for power on/off

Power connector

• Connector for power supply (alternating current)

Performance2

Firewall Throughput3

• 4 GB/s

VPN bandwidth4

• 1 GB/s

IPS throughput5

• 450 Mbps

Anti-virus throughput5

• 600 Mbps

Bandwidth control function applications5

• 700 Mbps

Max. number of parallel sessions

• 500 000000

How many new sessions per second

• 45 000000

Firewall policy

• 2000

Network

Type of Internet connection

• Static/dynamic IP address

• PPPoE/PPTP/L2TP

• Russia PPTP/L2TP (Dual Access)

• Russia PPPoE (Dual Access)

Firewall

• NAT, PAT

• Dynamic Routing Protocol: OSPFv2

• Application Layer Gateway

-HTTP

-FTP

-H. 323

-POP3

-SMTP

-SIP

-TFTP

-TLS 1.0 (RFC2246)

• Transparent mode (Transparent mode)

• H. 323 NAT Traversal

• Policy on a schedule

• Active network security ZoneDefense

• Authentication: the local database, RADIUS, Microsoft Active Directory, LDAP,

Network features

• DHCP Server/client

• DHCP Relay

• IP Multicast: IGMPv3

• IPv6

• Policy-based Routing

• IEEE 802 .1Q VLAN: up to 128 VLAN

• Channel Aggregation

Load balancing

• Balancing outgoing traffic

• Server load balancing

• Traffic redirection when Cliff channel (failover)

High Availability (HA)

• WAN channel Reservation

• Device failure Detection

• Sync sessions FW/VPN

• Active/Passive Mode

• Identification of breakage of the channel
